Pole Compatibility Matrix

The vaulting pole charts show the relationship between pole length and stiffness. If poles are on the same row (R#), then an athlete, in theory, can penetrate to the same depth in the pits (granted, the vaulter’s weight, speed, and technique are the same). For example, a vaulter using a 13’0” 170 will penetrate the pit at the same depth if they used a 13’6” 160 or a 14’0” 150.

# 10' 10'6" 11'0" 11'6" 12'0" 12'6" 13'0" 13'6" 14'0" 14'6" 15'0" 15'6" 16'0" 16'6"
1 100 90 80
2 105 95 85
3 110 100 90 80
4 115 105 95 85
5 120 110 100 90 80
6 125 115 105 95 85
7 130 120 110 100 90
8 135 125 115 105 95
9 140 130 120 110 100 90
10 145 135 125 115 105 95
11 150 140 130 120 110 100
12 145 135 125 115 105
13 150 140 130 120 110 100
14 145 135 125 115 105
15 150 140 130 120 110 100
16 155 145 135 125 115 105
17 160 150 140 130 120 110
18 155 145 135 125 115
19 160 150 140 130 120
20 165 155 145 135 125 115
21 170 160 150 140 130 120
22 165 155 145 135 125 115
23 170 160 150 140 130 120
24 175 165 155 145 135 125
25 180 170 160 150 140 130 120
26 175 165 155 145 135 125
27 180 170 160 150 140 130
28 185 175 165 155 145 135
29 180 170 160 150 140 130
30 185 175 165 155 145 135
31 190 180 170 160 150 140
32 185 175 165 155 145
33 190 180 170 160 150 140
34 195 185 175 165 155 145
35 200 190 180 170 160 150
36 195 185 175 165 155
37 200 190 180 170 160 150
